08-ANT-0879 | 5GHz WiFi (4.9 to 5.9GHz) 60-Degree Omni WiFi Antenna

sector antenna 5ghz 08-ANT-0879
Request Quote

WiFi Antenna 08-ANT-0879

  • 4.9GHz to 5.9GHz, 12 dBi
  • 60-Degree Directional Antenna
  • WiFi Antenna
  • Custom Configurations and Connectors
directional_azimuth_horizontal

Horizontal Radiation

Directional Radiation Pattern

directional_elevation_vertical

Vertical Radiation

Directional Radiation Pattern

description

WiFi antenna 08-ANT-0879 is a 120-degree directional antenna with a 5GHz WiFi (4.9 – 5.9GHz) frequency range. It’s multi-polarized and Made in the USA.

The Multi-Polarized Sector 60-5GHz is constructed of UV stabilized polymers and high grade aluminum for extremely long service life in the most demanding conditions. With a 60 degree directional antenna pattern it provides exceptional 12dBi high gain effective power and is ideal for indoor and outdoor deployments where a sectorized approach is required to accommodate clients in a variety of points.

Weighing only 10 oz, WiFi antenna 08-ANT-0879 can easily be mast or wall mounted with available mounting hardware. Multi-Polarized antenna technology provides unequalled wireless communication in “Real World” obstructed non-line-of-sight (NLOS) environments.

Applications

  • 5GHz ISM Band
  • Point-to-Point and Multipoint Systems
  • Wireless Broadband Systems
  • Access Point Router Bridge CPE
  • Building Penetration and High Obstruction Deployments

Features

  • Patented Multi-Polarized three dimensional element design
  • Obstruction Penetrating TX/RX
  • Built In Spatial Diversity
  • Excellent F/B (28 dB)
  • Light Weight/Low Wind Load
  • Mounting Hardware Included

Downloads

Data Sheet 08-ANT-0879 Antenna

photos

Specifications
Model Number
08-ANT-0879
Frequency Range
4.9GHz to 5.9GHz
Gain
12 dBi
VSWR
<1.5:1
Ground Plane
Built In
Color
White or Black
Antenna Feeds
One
Coax Length
N/A
Coax Type
N/A
Connector Type
Various
Polarization
Multi-Polarized
Power
50 Watts Input
Impedance
50 ohms nominal
Construction
UV Stabilized Polymers High Grade Aluminum
Environmental
Outdoor
Operation Temp
-40 to 85 deg C
Storage Temp
-40 to 85 deg C
Transport Temp
-40 to 85 deg C
IP Rating
IP66
Length
4 in
Width
3 in
Height
2 in
Weight
3 oz
Included Hardware
Mast or Wall Mount
